Some of the more well known forms of xDSL are listed below:
IDSL ISDN Digital Subscriber Line
HDSL High Bit-Rate Digital Subscriber Line
SDSL Symmetric Digital Subscriber Line
ADSL Asymmetric Digital Subscriber Line
VDSL Very High Bit-Rate Digital Subscriber Line
RADSL Rate Adaptive Asymmetric Digital Subscriber Line
All too often not considered within the scope of xDSL simply because ISDN is the commonly used terminology and has been internationally in use for many years. The two bearer channels of ISDN each deliver 64Kbp/s and may be bonded by a user application to provide a single delivery of 128Kbp/s. Again it is an application which “unpacks” the data. One advantage of ISDN is that the signalling protocol is entirely separate from the bearer channels and so “housekeeping” is an independent operation, hence basic rate is often referred to as 2B+D.
HDSL provides an improved method of transmitting T1 (1.55 Mbps) or E1 (2.048 Mbps) over twisted-pair copper lines. HDSL transmits 1.544 Mbps or 2.048 Mbps using bandwidths ranging from 80 kHz to 240 kHz instead of the 1.5 MHz used by AMI, the traditional method of transmitting T1/E1. Thislower frequency generates less corrup-tionof the cable spectrum enablingmore than one circuit in a multi-pairbundle. HDSL transmission uses typically 2 pairs for T1 and up to three pairs for E1. This may be seen as adisadvantage, however, it is highlylikely that these pairs will already be inplace and therefore will not require thecostly provision of new cables. A sec-ond version of HDSL, known somewhat unsurprisingly as HDSL II, can offer the ame performance as HDSL, but using a single twisted-pair. Deployment of HDSL II has a great deal of appeal to the large national carriers as it gives them all the benefits of using their installed base of copper pairs for high bandwidth applications yet minimises the number of pairs used. This tech-nique is now being deployed or tested in a number of countries.
SDSL is in essence a version of HDSL that can transmit T1 or E1 signals utilising a single twisted-pair, and typi-cally operating over POTS, giving the benefit of supporting POTS and T1/E1 simultaneously. There is, however, a distance limitation of around 10,000 feet. At face value SDSL would appear ideal for delivering high-speed access to individual subscriber premises for applications such as remote LAN or Internet access. Consideration, howev-er, should be given to the fact that ADSL can achieve higher data rates at the 10,000 feet limitation of SDSL andthat the typically usage of remote LAN and Internet access is by nature asymmetric.
ADSL Asymmetric Digital Subscriber Line
ADSL is one of the hottest topics around at the moment and it is easy to understand why. Depending on the form of ADSL deployed it is possible to achieve downstream (towards the user) speeds up to 8 Mbps and upstream (towards the service provider) speeds up to 1.5 Mbps. This asymmetric nature of ADSL makes it very attractive for applications that typically download much more data than is sent. The most obvious of these is Internet usage, however, video on demand is potentially the most exciting.
A variety of ADSL formats are being proposed at this time and they are all based on a trade-off between cost, complexity and performance. In vogue at the moment is G.Lite ADSL with downstream speed of 1.5Mbps and upstream of 384Kbps. This could well be the most user-friendly form of DSL and could become the implementation of choice for domestic users. The cost of equipment and service will almost certainly be lower than the other varieties of DSL.
VDSL is the highest speed DSL technology with data rates up to 52 Mbps downstream and up to 2.3 Mbps upstream. To achieve this speed the maximum distance from the exchange to the user is between 1,000 and 4,500 feet. VDSL is still very much at an experimental stage and no real world applications are in use.
RADSL Rate Adaptive Asymmetric Digital Subscriber Line
RADSL operates at the same band-widths as ADSL with the added ability of adjusting bandwidth to suit the quality of the line during the actual transmission.
Testing DSL technology
The advantages of xDSL technologies are self-evident, but what must we consider to be the potential problems?
In most cases we are dealing with a legacy infrastructure and topology which, because of bridge taps, mis-matching and the general degradation of the electrical characteristics of the line, may not be capable of supporting DSL services efficiently. The first step is to establish that the line is capable of supporting the chosen DSL technology and secondly, once operational, to be able to determine the fault should problems occur.
The procedures for this fall into two categories, analogue testing to determine the quality and appropriateness of the line and digital testing to determine the quality and correctness of the service. Quite simply, problems associated with quality of service can be caused by configuration issues or by the physical characteristics of the line, the latter requiring further analogue tests to determine the problem. The physical characteristics which determine DSL suitability include line length, cable suitability, bandwidth availability, environmental noise, thermal/mechanical effects, cross talk, impedance, terminations, bridge taps, insulation, and split pairs. Digital testing requires a tester with the capability to simulate a DSL modem or to replace the DSL modem, known in Trend as “Golden Modem” operation.
